> >Proop 10.1 Lite 10.1 inch Professional Operator Panel

Operator Panels HMI/PLC

Information

Proop 10.1 Lite 10.1 inch Professional Operator Panel View larger

Proop 10.1 Lite 10.1 inch Professional Operator Panel

New product

More info

Proop 10.1 Lite 10.1 inch Professional Operator Panel

10.1" high resolution TFT LCD display
Ethernet, RS-232 and RS-485 communication
Optional WiFi and Ethernet input

Features Descriptions
Graphics / Visual Features
Display Type 10.1 inc TFT
Display colors 16M color
Resolution 1024x600
Storage / Operating Temperature -20 ºC with +60 ºC / 0 ºC with +50 ºC
Physical Features 90 % max. (None condensing)
Dimensions 278 mm x 200 mm 50 mm
Panel section 265 x186 mm
Weight Approximately 1300g.
Technicial Specifications
Digital Inputs None
Digital Outputs None
Analogue Inputs None
Analgoue Outputs None
Serial Communication-2 RS-485 (Terminal) Maks. Hız : 57600
Serial Communication-3 RS-232 (Terminal) Maks. Hız : 230400
Serial Communication-4 RS-232 (DB-9 socket)
MCU ARM Cortex-A Series
Flash Memory 8GB eMMC
RAM 512 MB DDR3 SDRAM
Buzzer Build in >=85 dB
USB Device 1 x USB 2.0
USB Host 1 x USB 2.0
Optional Communication Wi-Fi (IEEE 80211 b/g/n), Ethernet (10/100 mbps full Duplex)
Communication Protocols Modbus-RTU, Modbus-ASCII, Modbus TCP/IP, Modbus-ASCII (Slave), Modbus-RTU (Slave), Modbus TCP/IP (Slave), ISOTCP (S7-300 , S7-400, S7-1200, S7-1500),  BACNET MS/TP, BACNET IP
Approvals CE , EAC
