> >TG 100 Dial Thermometers

Temperature Gauges

Information

TG 100 Dial Thermometers View larger

TG 100 Dial Thermometers

New product

More info

• Used where industrial accuracy is needed.
• Used with gas and liquids which do not attack stainless steel 316L.
• With its capillary tubing Thermometer’s body can be mounted away from heat source (max. 5mt)
• In vibrating environments silicon oil filled types should be used.
Industry Sector: Petro-chemical plants, Machinery Manufacturing, Heating, ventilation, air conditioning (HVAC) and vessel manufacturers

Usage Properties
Conformity
  • EN 13190
Accuracy Class
  • CL 2.0
Protection Rate
  • IP 55
Storage Temperature
  • -40 ... +70 °C
Constructive Properties
Mounting Type
  • Bottom Connection
Scale Range (T)
  • -30/+60°C
  • 0/+120°C
  • 0/+160°C
  • 0/+300°C
Case
  • Stainless Steel AISI-304
Bezel
  • Stainless Steel AISI-304
Window
  • Polycarbonate
Connection
  • G 1/2’’ B
Dial
  • Aluminum
Pointer
  • Aluminum
Contact Types
  • Indcutive
  • 1NO
  • 1NC
  • 2NONO
  • 2NONC
  • 2NCNC
  • 2NCNO
Temperature Element
  • Gas Actuated
Thermowell
  • Stainless Steel AISI-316
Immersion Length
  • 200mm
Capillary Tube Length
  • 3m
  • 5m
